UL1015 Elecreic PVC Wire, 600V 105℃ 26 to 10 AWG
UL1015 Elecreic PVC Wire
UL1015 is a UL-certified electrical wire with PVC insulation and stranded tinned copper conductors, designed for reliability in demanding environments. Rated for 105°C and 600V, it is widely used in appliances, industrial machinery, automotive systems, and control panels. Its durable PVC insulation resists moisture, chemicals, and abrasion, while flexibility simplifies installation. Available in multiple gauges (26–10AWG) and colors for easy identification, UL1015 complies with stringent safety standards and RoHS directives. Ideal for high-temperature or mechanically stressful settings, it ensures safe, durable power delivery in commercial and industrial applications, balancing performance with global compliance.
Features
- Temperature & Voltage Ratings: Rated for up to 105°C and 600 volts, ensuring performance in demanding environments.
- Conductor: Stranded, tinned copper provides excellent conductivity, corrosion resistance, and ease of soldering.
- Insulation: Durable PVC offers flexibility, resistance to moisture, chemicals, and abrasion. Suitable for dry and damp locations.
- Gauge Range: Available in 26 AWG to 10 AWG, accommodating diverse current-carrying needs.
- Colo: red, orange, yellow, green, blue, purple, white, black, brown, pink, gray, etc.
Specifications
| 导体 Conductor | 绝缘 Insulation | Maximum Conductor Resistance 最大导体直流电阻 (Ω/Km,20℃) |
Dielectric Strength 耐压强度 (Vac,1min) |
|||
| 规格 Size (AWG) |
构造 Construction (No/mm) |
外经 Dia (mm) |
厚度 Thickness (mm) |
外经 O.D (mm) |
||
| 26 | 7/0.160 | 0.48 | 0.76 | 2.1 | 150 | 2000 |
| 24 | 11/0.160 | 0.61 | 0.76 | 2.2 | 94.2 | 2000 |
| 22 | 17/0.160 | 0.76 | 0.76 | 2.4 | 59.4 | 2000 |
| 20 | 26/0.160 | 0.94 | 0.76 | 2.6 | 37.6 | 2000 |
| 18 | 41/0.160 | 1.18 | 0.76 | 2.8 | 23.9 | 2000 |
| 16 | 26/0.254 | 1.49 | 0.76 | 3.1 | 15.1 | 2000 |
| 14 | 41/0.254 | 1.88 | 0.76 | 3.5 | 9.5 | 2000 |
| 12 | 65/0.254 | 2.36 | 0.76 | 4 | 6.3 | 2000 |
| 10 | 105/0.254 | 3.38 | 0.76 | 5 | 4.2 | 2000 |
Applications
UL1015 is widely used in environments requiring durable, heat-resistant wiring.
- Industrial Machinery: Motor leads, transformers, control panels, and power supply connections in factories, where flexibility and resistance to oils, chemicals, and abrasion are critical.
- Automotive Systems: Wiring for sensors, lighting, and internal harnesses in vehicles, thanks to its vibration resistance and ability to withstand underhood heat.
- Appliances & HVAC: Internal wiring for ovens, dryers, refrigerators, and HVAC units, where 105°C heat tolerance ensures safe operation near heating elements.
- Control Circuits: Low-voltage control wiring in automation systems, robotics, and PLCs, leveraging its color-coded insulation for easy identification.
- Power Tools & Equipment: Connections in drills, grinders, and industrial tools, where stranded tinned copper ensures reliable conductivity under mechanical stress.
- Medical Devices: Non-critical wiring in diagnostic equipment, where RoHS compliance and flame-retardant PVC meet safety standards.
- Renewable Energy: Inverters, solar panel connections, and battery systems, where durability and high-temperature performance are essential.
