Molex CMC/CMX Sealed Connector

The Molex CMC / CMX Sealed Connector System offers a wide range of high-density connectors and tools for the transportation industry. These connectors feature a compact design, matte-seal technology, and mechanical polarization. They are designed for high-conductivity applications in tough environments. The CMC-sealed hybrid automotive connectors support low, medium, and high-current applications from 2.5A to 21A and can be used in sealed applications requiring an IPx9K rating and 500 mbar water-tightness. The CMC connectors are perfect for heavy-duty tasks in the transportation industry, such as powertrain and body-electronics applications, including engine control units (ECUs), gearboxes, electronic park brakes, and suspension controllers. In addition to the connectors themselves, the Molex CMC/CMX Sealed Connector System includes useful accessories such as extractor tools, crimpers, and insertion tools.

Features

• Wide range of high-density connectors and tools for the transportation industry
• Compact connectors with matte seal technology and mechanical polarization
• CMC sealed hybrid automotive connectors are designed for high-conductivity applications in harsh environments
• Accessories include extractor tools, crimpers, insertion tools, and more

Connector P/N lists and Specs

CMC CMX Connector Applications

Powertrain Applications

• Engine Control Units (ECUs): The connectors ensure stable communication and power distribution, which is crucial for engine performance and diagnostics.
• Gearboxes: Their sealing properties prevent fluid intrusion, enhancing the durability of the gearbox's electronic components.
• Suspension Controllers: They support precise control of suspension systems, improving ride comfort and handling.
• Electronic Parking Brakes: These connectors offer reliable connections vital for safety and functionality.
• Body Electronics: Used in features like power windows and climate control systems, they enhance user convenience.
• Junction and Fuse Boxes: The robust design allows for secure connections in critical power distribution areas.
• Lighting Control Systems: Ensures consistent headlights, taillights, and interior lighting performance under various conditions.
• Electric Doors: The connectors facilitate the seamless operation of electric door mechanisms, enhancing vehicle accessibility.

Transportation Applications

• Cars and Trucks: Essential for various electronic systems, they improve reliability in everyday vehicles.
• Buses: Their rugged design supports the demands of public transportation, where durability is key.
• Agricultural Equipment: These connectors withstand exposure to dirt and moisture, crucial for reliable operation in the field.
• Construction Equipment: They provide essential connections in heavy machinery, where performance under stress is critical.
• Motorcycles: Compact and lightweight, they ensure reliable connections without adding unnecessary bulk.
• Marine: Designed to resist corrosion and harsh conditions, they are ideal for boats and other watercraft.

Support Custom Wire Harness Assembly

• Connectors series: 64321, 64320, 64318, 64319, and 34885.
• Connector circuits: 22 - 154 Pins
• Wire Gauge: 22AWG - 10AWG
• Wire Colors: Available in a wide range including white, black, red, yellow, blue, green, brown, orange, purple, grey, and more.
• Wire Length: Fully customizable to your specifications.
• Wiring Diagram: Tailor-made to meet your project needs.
• Custom type: Fully customizable to your specifications.
• Minimum Order: 50 pieces per order.

Customize Your Wire Harness

Send your sample or drawing/schematic for quote price→ Feedback with quotation(1~3 days) → Confirm quotation → Arrange sample you for approval→ [Make mold if needed (7 days) →Mold test] → Making samples(1~3 days)→ Samples test(Approval) → place order for Mass production(2~3 weeks)→ Quality checking→ Packing → Delivery → After Service → Repeat Order.
