Molex ConnTAK50 Connectors

Molex’s ConnTAK50 connectors are engineered to meet the rigorous demands of automotive applications, providing up to 22 circuits and supporting a current rating of 6.0A. This robust connector system is designed with a low mating force, which not only simplifies the mating process but also helps reduce labor costs and accelerates the assembly process. With a compact design featuring a 1.80mm pitch, the ConnTAK50 connectors utilize the Arbeitskreis (AK) interface, making them ideal for space-constrained environments. Available in both single- and dual-row configurations, these connectors offer versatility and design flexibility. The TAK50 terminals are also compatible with existing competitor AK connectors, enabling seamless integration. Noteworthy features include a patented connector position assurance (CPA) release mechanism that simplifies assembly and minimizes operator fatigue, along with a 2-piece beam design in the terminals that ensures electrical reliability and resistance to vibration. Additional options, such as wire dress covers, right-angle and vertical headers, and multiple polarization and color-keying configurations, further enhance design flexibility and ease of use, while minimizing the risk of mismating.

ConnTAK50 Connector Features

• Patented CPA release mechanism eases assembly and reduces operator fatigue
• The TAK50 terminal has a 2-piece beam design that delivers electrical reliability and withstands vibration
• A wire dress cover is available, offering greater flexibility in wire routing
• Dual-row receptacles feature both a side latch and connector position assurance (CPA) mechanism
• Right-angle and vertical headers are available for design flexibility
• Four polarization and color-keying options are available to aid assembly and prevent mismating

ConnTAK50 Connector Specifications Datasheet

Sort by the number of poles.

ConnTAK50 Connector Applications

Battery Management Systems (BMS)

These connectors play a critical role in connecting components within battery management systems, ensuring effective monitoring, balancing, and control of battery cells. Their design supports secure, stable connections essential for the safety and efficiency of electric and hybrid vehicle power systems.

Bluetooth

ConnTAK50 connectors enable robust connections for in-car Bluetooth® modules, ensuring seamless communication and data transfer between devices. This is crucial for hands-free calling, audio streaming, and other wireless functionalities within vehicles.

Camera Modules

These connectors support the integration of camera systems, including rear-view, side-view, and surround-view cameras. Reliable connections are essential for transmitting high-quality video signals, enhancing driver assistance systems, and ensuring safety features.

HVAC Systems

In heating, ventilation, and air conditioning (HVAC) systems, ConnTAK50 connectors help manage connections between various control units and sensors. Their durable design ensures reliable performance in regulating climate controls, air quality, and comfort settings within the vehicle.

In-Vehicle Switches

ConnTAK50 connectors are used to connect in-vehicle switches, such as those for windows, doors, and dashboard controls. Their compact and efficient design allows easy integration into tight spaces, ensuring consistent performance and ease of use.

Lighting

These connectors facilitate connections for both interior and exterior lighting systems, including headlights, tail lights, dashboard illumination, and ambient lighting. They ensure stable power transmission, which is essential for consistent brightness and reliability.

Seat/Mirror Controls

ConnTAK50 connectors are employed in systems controlling seat positioning and mirrors, enabling functions such as electronic adjustments, heating, and memory settings. Their secure and durable connections help maintain consistent performance, even with frequent usage.

These examples illustrate the flexibility of Molex ConnTAK50 Automotive Connectors in accommodating a wide range of automotive systems, contributing to the overall functionality, safety, and comfort of modern vehicles.

Support Custom Wire Harness Assembly

• Connectors series: 205825, 205826, and 205827.
• Connector circuits: 2 - 22 Pins
• Wire Gauge: 0.13 - 0.35mm²
• Wire Colors: Available in a wide range including white, black, red, yellow, blue, green, brown, orange, purple, grey, and more.
• Wire Length: Fully customizable to your specifications.
• Wiring Diagram: Tailor-made to meet your project needs.
• Custom type: Fully customizable to your specifications.
• Minimum Order: 200 pieces per order.

Customize Your Wire Harness

Send your sample or drawing/schematic for quote price→ Feedback with quotation(1~3 days) → Confirm quotation → Arrange sample you for approval→ [Make mold if needed (7 days) →Mold test] → Making samples(1~3 days)→ Samples test(Approval) → place order for Mass production(2~3 weeks)→ Quality checking→ Packing → Delivery → After Service → Repeat Order.
