Molex KK 508 Connector

The Molex KK 508 Connector System is designed to provide reliable performance for low- to mid-range power applications, delivering up to 7.0A per circuit in wire-to-board configurations and 5.0A per circuit in board-to-board setups. Equipped with Glow Wire capability, the system meets stringent safety requirements, making it suitable for global use. The connectors feature a polarized mating geometry that ensures secure and correct connections, preventing mismating. For enhanced electrical reliability, the bifurcated terminals offer two independent contact beams, while the dual-cantilever terminals provide consistent electrical contact. Additionally, anti-snag terminals prevent damage during cable assembly, improving durability. With a standard 5.08mm pitch, the KK 508 system is versatile, accommodating various power needs. Its availability in multiple configurations, including top-entry, right-angle, and bottom-entry PCB receptacles, provides design flexibility, making it adaptable for a wide range of applications.

KK 508 Connector Features

• Polarized mating geometry, Ensures header and receptacle cannot be mismated
• Available in UL 94V-2 and/or Glow Wire capable materials, Is suitable for global applications that must meet regional safety standards
• Bifurcated terminal available, Enhances electrical reliability with two independent contact beams
• Dual-cantilever terminals, Create a reliable electrical connection
• Anti-snag terminals offered to prevent terminal damage during the cable assembly process
• Industry-standard 5.08mm pitch, Enables use in a variety of power applications
• Top-entry, right-angle, and bottom-entry PCB receptacles are available, Provide design flexibility

KK 508 Connector Specifications Chart

Sort by the number of circuits.

KK 508 Connector Applications

The Molex KK 508 Connector System is versatile and finds applications across a range of industries due to its reliable performance and flexible design. In the consumer sector, it is commonly used in home appliances, such as refrigerators, washing machines, and kitchen gadgets, where dependable electrical connections are essential. It also supports HVAC systems, providing efficient power transmission in heating, ventilation, and air conditioning units.

In data communications, the KK 508 connectors are utilized in networking equipment, servers, and data storage devices, ensuring stable connections for efficient data transfer. Office equipment, such as printers, copiers, and desktop computers, also benefit from the connector’s robust design, which maintains reliable connections under frequent usage.

In the industrial sector, connectors play a crucial role in automation equipment, including robotic systems, conveyor belts, and control units, where consistent power delivery is critical for smooth operations. Additionally, they are used in industrial networks to support reliable communication between devices, helping maintain efficient workflows in factory and manufacturing settings.

These applications highlight the connector’s adaptability and robust design, making it a suitable choice for both standard and demanding environments.

Support Custom Wire Harness Assembly

• Connectors series: 3001, 91813.
• Connector circuits: 2 - 12 Pins
• Wire Gauge: 18 - 26AWG
• Wire Colors: Available in a wide range including white, black, red, yellow, blue, green, brown, orange, purple, grey, and more.
• Wire Length: Fully customizable to your specifications.
• Wiring Diagram: Tailor-made to meet your project needs.
• Custom type: Fully customizable to your specifications.
• Minimum Order: 200 pieces per order.

Customize Your Wire Harness

Send your sample or drawing/schematic for quote price→ Feedback with quotation(1~3 days) → Confirm quotation → Arrange sample you for approval→ [Make mold if needed (7 days) →Mold test] → Making samples(1~3 days)→ Samples test(Approval) → place order for Mass production(2~3 weeks)→ Quality checking→ Packing → Delivery → After Service → Repeat Order.
