Molex Micro-One Connector

Molex Micro-One Wire-to-Board Connectors are designed with an Integrated Independent Secondary Lock (ISL) feature to ensure secure terminal positioning and avoid accidental disconnections, providing enhanced reliability even in high-vibration settings. This secondary lock mechanism reinforces the connection by securing each terminal firmly, thereby preventing potential back-outs and maintaining a stable electrical link. The compact 2mm pitch, low-profile form factor is ideal for space-constrained applications, while UL and CSA certifications guarantee compliance with industry standards. With a maximum voltage rating of 250V and a current capacity of up to 4A, the Micro-One series is suitable for demanding power and signal applications. These connectors also ensure durability with a minimum of 30 mating cycles, making them a reliable solution for applications requiring frequent reconnections.

Micro-One Connector Features

• 2mm pitch low-profile design
• UL/CSA certified connectors ensure reliability
• ISL detects incomplete terminal insertion
• 2- to 8-circuit vertical and right-angle head assemblies
• A terminal position assurance option is also available
• Potting-capable headers available
• Glow wire capable
• Natural and black housings are available for color-coding
• 250V maximum voltage
• 4A maximum current (2 circuit, 22AWG)
• 30 cycles minimum durability
• -40°C to +105°C operating temperature range

Micro-One Connector Specifications Chart

Sort by the number of circuits.

Micro-One Connector Applications

Industrial Applications

1. Power Tools: In industrial and commercial power tools, the Molex Micro-One Connector enables stable, high-power connections in a compact design. Its durability and secure fit are ideal for applications where vibration or heavy handling are common, ensuring that tools remain functional even under challenging conditions.

2. Test Equipment: Testing instruments require reliable connections to capture precise data, often in harsh environments. The Micro-One Connector is engineered to withstand frequent connect and disconnect cycles, making it suitable for quality testing equipment, diagnostic tools, and field-test devices.

3. Robots: Industrial robots and robotic arms benefit from the compact and secure nature of the Micro-One Connector, which supports efficient space usage in control systems. These connectors offer the stability needed for robotic applications that experience constant motion, power demands, and require seamless data flow.

4. Factory Automation: For equipment in automated factories, the Molex Micro-One provides dependable connections for sensors, control modules, and other components that power automated processes. Its reliable performance is crucial for applications that demand minimal downtime and high efficiency.

5. Drones: Compact and lightweight, the Micro-One Connector is an excellent choice for drones, where weight and space are limited. Its low-profile design minimizes bulk while maintaining a strong, consistent connection for power and communication lines in consumer, commercial, and industrial drones.

6. Vending Machines: Vending machines often operate continuously and require reliable internal connections. The Molex Micro-One Connector supports consistent power and control functions within these machines, ensuring smooth operation for extended periods and in various environmental conditions.

Consumer Applications

1. Refrigerators: Within modern refrigerators, the Molex Micro-One Connector provides dependable connections for essential functions like cooling system control, sensors, and LED displays. Its reliability ensures consistent operation, reducing the risk of connection failures that could compromise performance.

2. Air Conditioners: The Micro-One Connector supports the compact and powerful design of modern air conditioners, providing essential connections between circuit boards, sensors, and power modules. It ensures that the air conditioning systems function smoothly even under frequent on-off cycles and varying temperatures.

3. Hot Water Gas Heaters: In hot water gas heaters, the Molex Micro-One supports control panel connections, safety sensors, and ignition systems. Its design allows it to perform well in conditions where heat and humidity are prevalent, contributing to the safety and reliability of the heater.

4. Washing Machines: The reliable connections provided by the Micro-One Connector are crucial for washing machine control panels, sensors, and motor circuits. Its durability under vibration and moisture exposure enhances the washing machine's performance, ensuring long-term, trouble-free operation.

The Molex Micro-One Connector is not limited to these applications. Its compact size, robust construction, and versatile design allow it to be adapted to a broad range of other industrial and consumer devices that require reliable wire-to-board connections. This makes it a flexible solution suitable for both current and future design challenges across multiple industries.

Support Custom Wire Harness Assembly

• Connector circuits: 2 - 8 Pin
• Wire Gauge: 22 - 28AWG, depends on real needs
• Wire Colors: Available in a wide range including white, black, red, yellow, blue, green, brown, orange, purple, grey, and more.
• Wire Length: Fully customizable to your specifications.
• Wiring Diagram: Tailor-made to meet your project needs.
• Custom type: Fully customizable to your specifications.
• Minimum Order: 100 pieces per order.

Customize Your Wire Harness

Send your sample or drawing/schematic for quote price→ Feedback with quotation(1~3 days) → Confirm quotation → Arrange sample you for approval→ [Make mold if needed (7 days) →Mold test] → Making samples(1~3 days)→ Samples test(Approval) → place order for Mass production(2~3 weeks)→ Quality checking→ Packing → Delivery → After Service → Repeat Order.
