Molex Milli-Grid Connector

The Molex Milli-Grid 2.0mm Pitch Connector System is designed to provide versatile and reliable interconnect solutions for a variety of applications, including wire-to-board, board-to-board, and cable-to-board connections. With its compact 2mm x 2mm grid pattern, this connector system delivers exceptional design flexibility, making it ideal for use in industries such as consumer electronics, telecommunications, and PC hardware. The Milli-Grid connectors are engineered with IDT (Intermittent Disconnect Technology) receptacle strain relief, which not only ensures robust cable retention but also enhances contact stability by providing a secure locking mechanism with locking ramps. Available in both black and grey high-temperature housing materials, these connectors are rated to UL 94V-0 for flame resistance and are capable of operating within a broad temperature range of -55°C to 105°C. They are designed for optimal electrical performance with a minimum insulation resistance of 1000MΩ and a maximum contact resistance of 40mΩ. The Molex Milli-Grid 2.0mm Pitch Connector System is commonly used in a variety of applications, including vending machines, gaming machines, fitness equipment, satellite radios, and security systems, providing dependable, high-performance connectivity in a range of demanding environments.

Milli-Grid Connector Features

• Fully shrouded housing
• Wide lead-in bevel design
• Floating x- and y-axes
• High-temperature LCP housing
• Choice of six PC tail lengths (2.10 mm, 2.60 mm, 3.00 mm, 3.50 mm, 4.00 mm, and 4.50 mm)
• Locating peg
• Protects mating contact from accidental bending and damage
• Self-aligns connectors without the need for direct line-of-sight or wrenching tools
• Helps position connectors to achieve fully mated condition
• Meets lead-free processing requirements
• Suits a variety of PCB thicknesses for greater design flexibility
• Ensures correct connector orientation on PCB
• Contact resistance: 15mΩ to 40mΩ
• Current rating: 1A to 2A
• Dielectric withstanding voltage: 500V AC (RMS)
• Minimum insulation resistance: 1000MΩ
• Operating temperature range: -55°C to 105°C
• Voltage rating: 125V AC

Milli-Grid Connector Specifications Chart

Sort by the number of circuits.

Milli-Grid Connector Applications

Automotive and Commercial Vehicles

The Milli-Grid connector is widely used in automotive and commercial vehicle systems that require secure and compact connections. Key applications include:

• Car Audio Systems: Ensures stable connections for consistent audio quality and performance within vehicle infotainment systems.
• Data and Telemetry Systems: Supports connections in data-logging and telemetry devices, essential for vehicle diagnostics and real-time data monitoring.
• GPS Navigation: Facilitates reliable connectivity in GPS modules, supporting consistent location data tracking and navigation guidance.

Computers and Peripherals

Milli-Grid connectors also suit computer hardware and peripherals due to their high density and adaptability in compact spaces. Applications include:

• Modems: Provides reliable connectivity in network devices, allowing for uninterrupted data transmission.
• Monitors: Ensures stable and clear signals for display devices, enhancing video and visual performance.
• Motherboards: Connect critical components within motherboards, enabling smooth communication across computing systems.

Telecom

Telecommunication devices benefit from the Milli-Grid's ability to support high-density, multi-point connections in a compact form, essential in networking equipment:

• Hubs: Connects various network devices, facilitating streamlined data traffic management within telecom infrastructures.
• Switches: Supports stable, high-speed connections for data transmission between devices, ensuring efficient network performance.
• Routers: Enables secure connectivity within routing devices, critical for data flow and internet connectivity in telecom networks.

Consumer Electronics

The Milli-Grid connector meets the needs of various consumer electronics, supporting connectivity in equipment used at home and in offices:

• Copiers: Connects key internal systems, ensuring consistent document processing capabilities.
• Fax Machines: Provides stable connections for reliable data transmission in multifunctional office equipment.
• Printers: Enables seamless communication between components, supporting efficient and high-speed printing processes.
• Satellite Radio: Delivers reliable connectivity in satellite radio devices, ensuring consistent reception and broadcast quality.

This is not an exhaustive list of applications for the Molex Milli-Grid Connector. While these examples represent some common uses, the connector's adaptability allows it to serve in numerous other systems across industries.

Support Custom Wire Harness Assembly

• Connector circuits: 2 - 50 Pin
• Wire Gauge: 22 - 30AWG, depends on real needs
• Wire Colors: Available in a wide range including white, black, red, yellow, blue, green, brown, orange, purple, grey, and more.
• Wire Length: Fully customizable to your specifications.
• Wiring Diagram: Tailor-made to meet your project needs.
• Custom type: Fully customizable to your specifications.
• Minimum Order: 100 pieces per order.

Customize Your Wire Harness

Send your sample or drawing/schematic for quote price→ Feedback with quotation(1~3 days) → Confirm quotation → Arrange sample you for approval→ [Make mold if needed (7 days) →Mold test] → Making samples(1~3 days)→ Samples test(Approval) → place order for Mass production(2~3 weeks)→ Quality checking→ Packing → Delivery → After Service → Repeat Order.
