Molex Mini-Fit TPA, TPA2 Connector
The Molex Mini-Fit TPA connectors bring enhanced security to power applications with their unique Terminal Position Assurance (TPA) mechanism. This highly visible TPA pin confirms when each terminal is securely seated within the housing, ensuring that connections remain locked during assembly, mating, and regular operation. By preventing terminals from backing out, these connectors contribute to consistent, reliable power delivery. Equipped with a Connector Position Assurance (CPA) feature, the Mini-Fit TPA connectors also prevent unintended disconnection between male and female connectors. This design flexibility allows them to accommodate standard Mini-Fit crimp terminals, which simplifies integration, reduces design complexity, and accelerates qualification processes. Available in wire-to-wire and wire-to-board configurations, the Mini-Fit TPA series is versatile, supporting a wide range of circuit sizes from 2 to 16 positions and wire gauges from 16 to 28 AWG.
The Mini-Fit TPA2 connectors are engineered to meet the demands of high-current, high-density power applications across various industries. Designed with polarized housings, isolated terminals, and low-engagement forces, these connectors ensure proper alignment and prevent mismating, minimizing the risk of assembly errors. The TPA2 series features an advanced locking mechanism with an audible “click” that confirms secure mating, while isolated header pins and terminals prevent contact damage during handling and mating. The TPA2 connectors also include a secondary locking feature, which keeps terminals securely in place, even under mechanical strain, to reduce the risk of disconnection. Backward compatibility with Mini-Fit Jr. headers provides a seamless upgrade path for existing systems, with a 9.0 A current rating that meets the demands of modern power requirements without costly redesigns.
Mini-Fit TPA, TPA2 Connector Features
TPA
- TPA lock inserts into plug and receptacle housings to ensure that terminals are fully seated and guarantees that the terminals will not back out
- The optional CPA (Connector Position Assurance) key prevents accidental unmating
- No new tooling is required
- Up to 13.0 A per pin for increased current carrying capabilities
- Offered in wire-to-wire and wire-to-board configurations; headers available in mounting pegs or screw-mount flanges
TPA2
- Terminal position assurance (TPA) with a secondary locking feature
- Reduces assembly error
- Ensures terminals are fully seated and will not back out
- Positive-lock receptacle
- Ensures mated connector assemblies will not accidentally disengage
- Provides audible click while mating
- Fully isolated header pins and plug and receptacle terminals protect contacts against potential damage during handling and mating
- Compatible with existing Mini-Fit Jr. headers and plugs
- Enables running-change implementation to incorporate the TPA2.0 design
- Removes the need to change both sides of the interface or to make significant revisions or investments in applications
Mini-Fit TPA, TPA2 Connector Specifications Chart
Sort by the number of circuits.
| P/N | Old P/N | Circuits | Row | Pitch | Descriptions | Datasheet |
| 1727080002 | 172708-0002 | 2 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727080002#documents-and-resources |
| 1727080102 | 172708-0102 | 2 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727080102#documents-and-resources |
| 1727620002 | 172762-0002 | 2 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727620002#documents-and-resources |
| 1727620102 | 172762-0102 | 2 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727620102#documents-and-resources |
| 1727670002 | 172767-0002 | 2 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670002#documents-and-resources |
| 1727670102 | 172767-0102 | 2 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670102#documents-and-resources |
| 2004530002 | 200453-0002 | 2 | Single Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/2004530002#documents-and-resources |
| 2004530102 | 200453-0102 | 2 | Single Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/2004530102#documents-and-resources |
| 2004710002 | 200471-0002 | 2 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/2004710002#documents-and-resources |
| 2004880002 | 200488-0002 | 2 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/2004880002#documents-and-resources |
| 2004881002 | 200488-1002 | 2 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/2004881002#documents-and-resources |
| 2004881102 | 200488-1102 | 2 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/2004881102#documents-and-resources |
| 2004530003 | 200453-0003 | 3 | Single Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/2004530003#documents-and-resources |
| 2004530103 | 200453-0103 | 3 | Single Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/2004530103#documents-and-resources |
| 2004710003 | 200471-0003 | 3 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/2004710003#documents-and-resources |
| 2004880003 | 200488-0003 | 3 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/2004880003#documents-and-resources |
| 2004881003 | 200488-1003 | 3 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/2004881003#documents-and-resources |
| 2004881103 | 200488-1103 | 3 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/2004881103#documents-and-resources |
| 1727080004 | 172708-0004 | 4 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727080004#documents-and-resources |
| 1727080104 | 172708-0104 | 4 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727080104#documents-and-resources |
| 1727620004 | 172762-0004 | 4 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727620004#documents-and-resources |
| 1727620104 | 172762-0104 | 4 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727620104#documents-and-resources |
| 1727670004 | 172767-0004 | 4 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670004#documents-and-resources |
| 1727670104 | 172767-0104 | 4 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670104#documents-and-resources |
| 1727671004 | 172767-1004 | 4 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Old Panel Mount | https://www.molex.com/en-us/products/part-detail/1727671004#documents-and-resources |
| 1727671104 | 172767-1104 | 4 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable，Old Panel Mount | https://www.molex.com/en-us/products/part-detail/1727671104#documents-and-resources |
| 2004530004 | 200453-0004 | 4 | Single Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/2004530004#documents-and-resources |
| 2004530104 | 200453-0104 | 4 | Single Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/2004530104#documents-and-resources |
| 2004710004 | 200471-0004 | 4 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/2004710004#documents-and-resources |
| 2004880004 | 200488-0004 | 4 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/2004880004#documents-and-resources |
| 2004880104 | 200488-0104 | 4 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/2004880104#documents-and-resources |
| 2004881004 | 200488-1004 | 4 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/2004881004#documents-and-resources |
| 2004881104 | 200488-1104 | 4 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/2004881104#documents-and-resources |
| 2004530005 | 200453-0005 | 5 | Single Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/2004530005#documents-and-resources |
| 2004530105 | 200453-0105 | 5 | Single Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/2004530105#documents-and-resources |
| 2004710005 | 200471-0005 | 5 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/2004710005#documents-and-resources |
| 2004880005 | 200488-0005 | 5 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/2004880005#documents-and-resources |
| 2004881005 | 200488-1005 | 5 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/2004881005#documents-and-resources |
| 2004881105 | 200488-1105 | 5 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/2004881105#documents-and-resources |
| 1727080006 | 172708-0006 | 6 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727080006#documents-and-resources |
| 1727080106 | 172708-0106 | 6 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727080106#documents-and-resources |
| 1727620006 | 172762-0006 | 6 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727620006#documents-and-resources |
| 1727620106 | 172762-0106 | 6 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727620106#documents-and-resources |
| 1727670006 | 172767-0006 | 6 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670006#documents-and-resources |
| 1727670106 | 72767-0106 | 6 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670106#documents-and-resources |
| 1727671006 | 172767-1006 | 6 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Old Panel Mount | https://www.molex.com/en-us/products/part-detail/1727671006#documents-and-resources |
| 1727671106 | 172767-1106 | 6 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable，Old Panel Mount | https://www.molex.com/en-us/products/part-detail/1727671106#documents-and-resources |
| 2004530006 | 200453-0006 | 6 | Single Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/2004530006#documents-and-resources |
| 2004530106 | 200453-0106 | 6 | Single Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/2004530106#documents-and-resources |
| 2004880006 | 200488-0006 | 6 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/2004880006#documents-and-resources |
| 2004881006 | 200488-1006 | 6 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/2004881006#documents-and-resources |
| 2004881106 | 200488-1106 | 6 | Single Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/2004881106#documents-and-resources |
| 1727080008 | 172708-0008 | 8 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727080008#documents-and-resources |
| 1727080108 | 172708-0108 | 8 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727080108#documents-and-resources |
| 1727620008 | 172762-0008 | 8 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727620008#documents-and-resources |
| 1727620108 | 172762-0108 | 8 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727620108#documents-and-resources |
| 1727670008 | 172767-0008 | 8 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670008#documents-and-resources |
| 1727670108 | 172767-0108 | 8 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670108#documents-and-resources |
| 1727671008 | 172767-1008 | 8 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Old Panel Mount | https://www.molex.com/en-us/products/part-detail/1727671008#documents-and-resources |
| 1727671108 | 172767-1108 | 8 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable，Old Panel Mount | https://www.molex.com/en-us/products/part-detail/1727671108#documents-and-resources |
| 1727080010 | 172708-0010 | 10 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727080010#documents-and-resources |
| 1727080110 | 172708-0110 | 10 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727080110#documents-and-resources |
| 1727620010 | 172762-0010 | 10 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727620010#documents-and-resources |
| 1727620110 | 172762-0110 | 10 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727620110#documents-and-resources |
| 1727670010 | 172767-0010 | 10 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670010#documents-and-resources |
| 1727670110 | 172767-0110 | 10 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670110#documents-and-resources |
| 1727671010 | 172767-1010 | 10 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Old Panel Mount | https://www.molex.com/en-us/products/part-detail/1727671010#documents-and-resources |
| 1727671110 | 172767-1110 | 10 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable，Old Panel Mount | https://www.molex.com/en-us/products/part-detail/1727671110#documents-and-resources |
| 1727080012 | 172708-0012 | 12 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727080012#documents-and-resources |
| 1727080112 | 172708-0112 | 12 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727080112#documents-and-resources |
| 1727620012 | 172762-0012 | 12 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727620012#documents-and-resources |
| 1727620112 | 172762-0112 | 12 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727620112#documents-and-resources |
| 1727670012 | 172767-0012 | 12 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670012#documents-and-resources |
| 1727670112 | 172767-0112 | 12 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670112#documents-and-resources |
| 1727671012 | 172767-1012 | 12 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Old Panel Mount | https://www.molex.com/en-us/products/part-detail/1727671012#documents-and-resources |
| 1727671112 | 172767-1112 | 12 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2，Glow-Wire Capable，Old Panel Mount | https://www.molex.com/en-us/products/part-detail/1727671112#documents-and-resources |
| 1727080014 | 172708-0014 | 14 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727080014#documents-and-resources |
| 1727080114 | 1727708-0114 | 14 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727080114#documents-and-resources |
| 1727670014 | 172767-0014 | 14 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670014#documents-and-resources |
| 1727670114 | 172767-0114 | 14 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2 Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670114#documents-and-resources |
| 1727080016 | 172708-0016 | 16 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727080016#documents-and-resources |
| 1727080116 | 172708-0116 | 16 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727080116#documents-and-resources |
| 1727670016 | 172767-0016 | 16 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670016#documents-and-resources |
| 1727670116 | 172767-0116 | 16 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2 Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670116#documents-and-resources |
| 1727080018 | 172708-0018 | 18 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727080018#documents-and-resources |
| 1727080118 | 172708-0118 | 18 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727080118#documents-and-resources |
| 1727670018 | 172767-0018 | 18 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670018#documents-and-resources |
| 1727670118 | 172767-0118 | 18 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2 Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670118#documents-and-resources |
| 1727080020 | 172708-0020 | 20 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727080020#documents-and-resources |
| 1727080120 | 172708-0120 | 20 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727080120#documents-and-resources |
| 1727670020 | 172767-0020 | 20 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670020#documents-and-resources |
| 1727670120 | 172767-0120 | 20 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2 Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670120#documents-and-resources |
| 1727080022 | 172708-0022 | 22 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727080022#documents-and-resources |
| 1727080122 | 172708-0122 | 22 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727080122#documents-and-resources |
| 1727670022 | 172767-0022 | 22 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670022#documents-and-resources |
| 1727670122 | 172767-0122 | 22 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2 Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670122#documents-and-resources |
| 1727080024 | 172708-0024 | 24 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-0，Low-Halogen | https://www.molex.com/en-us/products/part-detail/1727080024#documents-and-resources |
| 1727080124 | 172708-0124 | 24 | Dual Row | 4.20mm | Mini-Fit TPA2 Receptacle Housing，UL 94V-2，Glow-Wire Capable | https://www.molex.com/en-us/products/part-detail/1727080124#documents-and-resources |
| 1727670024 | 172767-0024 | 24 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-0，Low-Halogen，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670024#documents-and-resources |
| 1727670124 | 172767-0124 | 24 | Dual Row | 4.20mm | Mini-Fit TPA2 Plug Housing，UL 94V-2 Glow-Wire Capable，Panel Mount | https://www.molex.com/en-us/products/part-detail/1727670124#documents-and-resources |
Mini-Fit TPA, TPA2 Connector Applications
1. Consumer/Home Appliances
Ideal for powering and connecting components within refrigerators, microwaves, washing machines, and other large and small appliances, where consistent electrical connections are critical.
2. Data/Communications
Found in networking equipment, server infrastructure, and storage devices, these connectors support reliable data transfer and power connectivity in high-density setups for both consumer and enterprise communications.
3. Office Equipment
Mini-Fit TPA and TPA2 connectors serve in office printers, copiers, and scanners, ensuring smooth operation and dependable power delivery for daily business functions.
4. Automotive
In automotive interiors, these connectors are used in lighting systems, infotainment modules, and seating components, providing secure connections without needing sealing in less exposed environments.
5. Harness Manufacturers
As a staple component for harness assembly, they provide a trusted, easy-to-integrate solution for a wide range of customer specifications and custom applications.
6. Non-Sealed Applications
Since the connectors are unsealed, they’re suited for indoor or protected environments where dust, water, and extreme weather protection aren’t a requirement.
7. Inside Devices
Commonly embedded within devices, these connectors provide compact and efficient power connections without taking up excessive space, making them ideal for confined environments.
8. Industrial Automation Equipment
Used in controllers, sensors, and machinery interfaces, these connectors deliver reliable connections in controlled industrial settings, supporting automation processes with high uptime.
9. Networks
These connectors are used in network infrastructure, such as routers, switches, and hubs, facilitating power and data connections essential for network functionality.
This list represents some of the more common applications for the Molex Mini-Fit TPA and TPA2 Connectors. They are widely adaptable and can meet the needs of additional industries and custom use cases outside of those listed here.
Support Custom Wire Harness Assembly
- Connector circuits: 2 - 24 Pin
- Wire Gauge: 16 - 28AWG, depending on real needs
- Wire Colors: Available in a wide range including white, black, red, yellow, blue, green, brown, orange, purple, grey, and more.
- Wire Length: Fully customizable to your specifications.
- Wiring Diagram: Tailor-made to meet your project needs.
- Custom type: Fully customizable to your specifications.
- Minimum Order: 100 pieces per order.
Molex Mini-Fit TPA2 Connector 2P Wire Harness
Molex Mini-Fit TPA2 Connector 4P Wire Harness
Molex Mini-Fit TPA2 Connector 6P Wire Harness
Molex Mini-Fit TPA2 Connector 8P Wire Harness
Customize Your Wire Harness
Send your sample or drawing/schematic for quote price→ Feedback with quotation(1~3 days) → Confirm quotation → Arrange sample you for approval→ [Make mold if needed (7 days) →Mold test] → Making samples(1~3 days)→ Samples test(Approval) → place order for Mass production(2~3 weeks)→ Quality checking→ Packing → Delivery → After Service → Repeat Order.
