Molex Mini-SPOX Connector

Molex's Mini-SPOX 2.50 mm wire-to-board connector system is engineered for compact applications requiring reliable electrical and mechanical performance, especially in automotive, consumer, and industrial settings. Designed to withstand harsh conditions, it features a friction lock for secure mating retention, offering resilience against shocks, vibrations, and rough handling that can disrupt connections. Its unique non-rectangular housing ensures proper mating orientation, reducing assembly errors in microminiature applications. With a small 2.50 mm pitch, the Mini-SPOX system is ideal for space-constrained PCBs, a common challenge in both consumer and automotive sectors. Available in single-row connectors with 2 to 15 circuits and in both vertical and right-angle configurations, the Mini-SPOX system also supports compatibility and simplifies procurement by offering a wide range of options suitable for multiple markets.

Mini-SPOX Connector Features

• 2 to 15 circuits, single row plug in vertical and horizontal configurations
• Offers design flexibility
• 2.50mm-pitch connector
• Provides space saving
• Uses popular crimp terminals
• Easy to access the crimp applicators as they are widely available in the market
• Terminal lance
• Fastened with the terminal to provide improved terminal retention
• Friction lock
• Provides better mating retention of housing and header
• Through hole round terminals
• Supports terminal ruggedness and reliability
• Polarizing features
• Ensures mating in proper orientation
• RoHS compliance and high-temperature capabilities
• Withstands harsh environments

Mini-SPOX Connector Specifications Chart

Mini-SPOX Connector Applications

Consumer Electronics

• White Goods: Connecting internal components of home appliances like washing machines and dishwashers.
• Gaming Machines: Providing stable power and signal connectivity in gaming consoles and arcade machines.
• Drones: Enabling lightweight and reliable connections for onboard electronics, enhancing control and stability.
• Air Conditioners: Ensuring efficient communication between control boards and internal parts.
• Laser Printers: Powering and coordinating motor functions, sensor connections, and control panels.
• Vacuum Cleaners: Supporting power and control signals for motors and electronic displays.
• Desktop PCs: Offering dependable connections for internal component interfacing and power distribution.
• Power Tools: Withstanding vibrations in cordless drills, saws, and other tools where robust connection reliability is essential.

Industrial Automation

• Automation Equipment: Interfacing control units with actuators, sensors, and other critical components in industrial systems.

Automotive

• Steering Wheel, Paddle Shift, and Combination Switches: Providing a compact interconnect solution for steering control systems.
• Shifters: Supporting the electronic components of shifting mechanisms.
• Head, Rear, and Side-Mirror Lights: Ensuring reliable illumination connections, critical for safety and aesthetics.
• Internal Connections: Facilitating integration between various control units and internal modules within the vehicle.

This list highlights only some of the common applications for the Molex Mini-SPOX 2.50mm Connectors; they are widely adaptable to other areas based on specific design requirements, emphasizing their versatility across industries.

Support Custom Wire Harness Assembly

• Connector circuits: 2 - 15 Pin
• Wire Gauge: 22 - 28AWG, depending on real needs
• Wire Colors: Available in a wide range including white, black, red, yellow, blue, green, brown, orange, purple, grey, and more.
• Wire Length: Fully customizable to your specifications.
• Wiring Diagram: Tailor-made to meet your project needs.
• Custom type: Fully customizable to your specifications.
• Minimum Order: 100 pieces per order.

Customize Your Wire Harness

Send your sample or drawing/schematic for quote price→ Feedback with quotation(1~3 days) → Confirm quotation → Arrange sample you for approval→ [Make mold if needed (7 days) →Mold test] → Making samples(1~3 days)→ Samples test(Approval) → place order for Mass production(2~3 weeks)→ Quality checking→ Packing → Delivery → After Service → Repeat Order.
