Molex Mizu-P25 Waterproof Connector

The Molex Mizu-P25™ Waterproof Connectors are specifically designed to protect sensitive electronics from dust and water intrusion, making them ideal for compact applications such as motorcycles and air conditioners, where space is at a premium and reliable connectivity is essential. This connector series includes two distinct sub-families tailored to meet varying voltage requirements: a low-voltage option rated up to 125 volts and a high-voltage option rated up to 250 volts. Both versions boast one of the smallest mated diameters in the market, making them an excellent choice for wire-to-wire applications that must pass through tight spaces, narrow openings, and complex hinge mechanisms. Additionally, the Mizu-P25 family enhances ease of use for operators through features like color-coded housings, low-insertion terminals for effortless assembly, and positive-lock mechanisms with polarization for secure, accurate mating every time. The thoughtful design of the Mizu-P25 system addresses both compactness and assembly efficiency, providing a robust solution for challenging environments.

Mizu-P25 Waterproof Connector Features

• IP67 rating provides complete dustproof and waterproof protection
• Compact size
• Positive locks ensure secure mating retention
• Integral seal stopper feature provides waterproof protection
• Spring-beam terminal design provides high pressure and small deflection for high-vibration applications
• Raised-body male terminal design provides polarization to prevent mismating
• Contact Resistance: 10mΩ max.
• Dielectric Withstanding Voltage: 500V AC/1 min.
• Insulation Resistance: 250MΩ min.
• Operating Temperature: -40°C to +105°C

Mizu-P25 Waterproof Connector Specifications Chart

Mizu-P25 Waterproof Connector Applications

Commercial Vehicles

• Boats: Ideal for marine environments, Mizu-P25 connectors offer reliable connections that withstand moisture, salt, and corrosion, ensuring dependable performance in challenging aquatic conditions.
• Motorcycles: Compact and rugged, Mizu-P25 connectors handle exposure to dust, vibrations, and weather, making them perfect for applications in lighting, ignition, and dashboard wiring systems.
• Tractors: Designed to handle the heavy-duty demands of agricultural equipment, these connectors support essential tractor systems and instrumentation, maintaining operational stability in dusty or muddy environments.

Consumer Electronics

• Air Conditioners: These connectors secure wiring in cooling and outdoor units, supporting dependable power and control connections that resist condensation and exposure to varying temperatures.
• Heated Toilet Seats: Mizu-P25 connectors are a key solution in humid environments, delivering secure connections in heated toilet systems where moisture and heat are present.
• Vending Machines: Providing reliable connections in vending machines, Mizu-P25 connectors help maintain power and control circuitry, especially in outdoor or high-traffic settings where they may be exposed to water and other environmental factors.

Industrial Applications

• LED Lighting: Ideal for both indoor and outdoor industrial lighting systems, these connectors provide waterproof, secure connections that withstand exposure to dust, humidity, and varying temperatures, helping to ensure lighting reliability.

Automotive Applications

• Door Electronics: Used in door locking and control systems, Mizu-P25 connectors help maintain secure, moisture-resistant connections in automotive doors that are exposed to external elements.
• Lamp Mirrors: Mizu-P25 connectors enable reliable connectivity for mirror illumination, ensuring performance despite exposure to condensation or temperature variations.
• Mirror Motor Harnesses: These connectors support motorized mirrors by providing compact, waterproof connections that endure vibration, movement, and potential moisture exposure.
• Powered Rear View Mirrors: The Mizu-P25 connectors provide secure, water-resistant connections for motorized rearview mirrors, supporting both power and control signals.
• Seating: In automotive seating systems, Mizu-P25 connectors ensure stable power and data transmission, critical for adjustable seats with built-in heating or cooling systems.
• Steering: Mizu-P25 connectors offer reliable connections within steering systems, allowing stable operation of electronic and control systems.
• Switches: These connectors provide durable connections for vehicle switch systems, helping to maintain secure, dust- and moisture-resistant circuitry.
• Wipers: Mizu-P25 connectors support the wiring in windshield wiper systems, ensuring consistent performance in wet conditions.

This list showcases some of the common applications for the Molex Mizu-P25 Waterproof Connectors but is not definitive. Their waterproof, compact design makes them suitable for a much broader range of applications, especially where moisture and environmental resistance are required.

Support Custom Wire Harness Assembly

• Connector circuits: 2, 3, 4 Pin
• Wire Gauge:20 - 22AWG, depending on real needs
• Wire Colors: Available in a wide range including white, black, red, yellow, blue, green, brown, orange, purple, grey, and more.
• Wire Length: Fully customizable to your specifications.
• Wiring Diagram: Tailor-made to meet your project needs.
• Custom type: Fully customizable to your specifications.
• Minimum Order: 100 pieces per order.

Customize Your Wire Harness

Send your sample or drawing/schematic for quote price→ Feedback with quotation(1~3 days) → Confirm quotation → Arrange sample you for approval→ [Make mold if needed (7 days) →Mold test] → Making samples(1~3 days)→ Samples test(Approval) → place order for Mass production(2~3 weeks)→ Quality checking→ Packing → Delivery → After Service → Repeat Order.
