Molex NSCC Connector
The Molex NSCC connector family delivers reliable unsealed wire-to-wire and wire-to-board power connections, designed to accommodate diverse application needs with circuit options ranging from 2 to 30. Engineered for efficiency, NSCC female receptacles feature an innovative one-piece design with an integrated hinged TPA (Terminal Position Assurance) function, ensuring secure terminal retention while reducing assembly complexity. These connectors support power delivery via 1.50mm and 2.80mm terminals, making them an ideal cost-effective solution for smaller circuit configurations. Fully compatible with SICMA, BTS, and TSC terminal systems, the NSCC connectors boast clean-body receptacle terminals for seamless terminal entry and enhanced operational efficiency in harness assembly. Their robust construction not only facilitates easy handling in production environments but also supports compatibility with grommet seals for additional versatility. Furthermore, color-coded keying simplifies installation and mitigates the risk of mismating, ensuring dependable performance and streamlined assembly processes.
NSCC connector Features
- One-piece, clean-body receptacle terminals for smooth terminal entry
- One-piece receptacles with integrated hinged TPA function
- Terminals produced in high-conductivity alloy
- ‘Go/no-go’ locking system with audible click
- Color coding linked to the mechanical keying
- 1.50mm and 2.80mm female terminals in high-conductivity alloy
NSCC connector Specifications Chart
Sort by the number of circuits.
| P/N | Old P/N | Circuits | Color | Pitch | Descriptions | Datasheet |
| 988171020 | 010009329 | 2 | White | 3.33mm | NSCC Single Part，Unsealed，1.50mm，Female Housing，Wire-to-Wire | https://www.molex.com/en-us/products/part-detail/988171020#documents-and-resources |
| 988171021 | 010009321 | 2 | Black | 3.33mm | NSCC Single Part，Unsealed，1.50mm，Female Housing，Wire-to-Wire | https://www.molex.com/en-us/products/part-detail/988171021#documents-and-resources |
| 988171025 | 10005325 | 2 | Green | 3.33mm | NSCC Single Part，Unsealed，1.50mm，Female Housing，Wire-to-Wire | https://www.molex.com/en-us/products/part-detail/988171025#documents-and-resources |
| 988171028 | 10008328 | 2 | Gray | 3.33mm | NSCC Single Part，Unsealed，1.50mm，Female Housing，Wire-to-Wire | https://www.molex.com/en-us/products/part-detail/988171028#documents-and-resources |
| 988191020 | 010509329 | 2 | White | 2.80mm / 5.00mm | NSCC Receptacle Connector，Single Part，Unsealed | https://www.molex.com/en-us/products/part-detail/988191020#documents-and-resources |
| 988191021 | 010501321 | 2 | Black | 2.80mm / 5.00mm | NSCC Receptacle Connector，Single Part，Unsealed | https://www.molex.com/en-us/products/part-detail/988191021#documents-and-resources |
| 988191025 | 010505325 | 2 | Green | 2.80mm / 5.00mm | NSCC Receptacle Connector，Single Part，Unsealed | https://www.molex.com/en-us/products/part-detail/988191025#documents-and-resources |
| 988221020 | 07519EV2F9 | 2 | White | 3.33mm | NSCC, Male Pin Connector，Non-Sealed | https://www.molex.com/en-us/products/part-detail/988221020#documents-and-resources |
| 988221021 | 07511EV2F1 | 2 | Black | 3.33mm | NSCC, Male Pin Connector，Non-Sealed | https://www.molex.com/en-us/products/part-detail/988221021#documents-and-resources |
| 988221025 | 07515EV2F5 | 2 | Green | 3.33mm | NSCC, Male Pin Connector，Non-Sealed | https://www.molex.com/en-us/products/part-detail/988221025#documents-and-resources |
| 988221028 | 07518EV2F8 | 2 | Gray | 3.33mm | NSCC, Male Pin Connector，Non-Sealed | https://www.molex.com/en-us/products/part-detail/988221028#documents-and-resources |
| 988241021 | 08211EV2F1 | 2 | Black | 2.80mm / 5.00mm | NSCC Pin Connector，Unsealed | https://www.molex.com/en-us/products/part-detail/988241021#documents-and-resources |
| 988241025 | 08215EV2F5 | 2 | Green | 2.80mm / 5.00mm | NSCC Pin Connector，Unsealed | https://www.molex.com/en-us/products/part-detail/988241025#documents-and-resources |
| 988171030 | 010109329 | 3 | White | 3.33mm | NSCC Single Part，Unsealed，1.50mm，Female Housing，Wire-to-Wire | https://www.molex.com/en-us/products/part-detail/988171030#documents-and-resources |
| 988171031 | 010101321 | 3 | Black | 3.33mm | NSCC Single Part，Unsealed，1.50mm，Female Housing，Wire-to-Wire | https://www.molex.com/en-us/products/part-detail/988171031#documents-and-resources |
| 988171035 | 010105325 | 3 | Green | 3.33mm | NSCC Single Part，Unsealed，1.50mm，Female Housing，Wire-to-Wire | https://www.molex.com/en-us/products/part-detail/988171035#documents-and-resources |
| 988211031 | 010301321 | 3 | Black | NSCC，Receptacle Connector Hybrid，Single Part，Unsealed | https://www.molex.com/en-us/products/part-detail/988211031#documents-and-resources | |
| 988211035 | 3 | Green | NSCC，Receptacle Connector Hybrid，Single Part，Unsealed | https://www.molex.com/en-us/products/part-detail/988211035#documents-and-resources | ||
| 988221030 | 07619EV3F9 | 3 | White | 3.33mm | NSCC, Male Pin Connector，Non-Sealed | https://www.molex.com/en-us/products/part-detail/988221030#documents-and-resources |
| 988221031 | 07611EV3F1 | 3 | Black | 3.33mm | NSCC, Male Pin Connector，Non-Sealed | https://www.molex.com/en-us/products/part-detail/988221031#documents-and-resources |
| 988171040 | 010209329 | 4 | White | 3.33mm | NSCC Single Part，Unsealed，1.50mm，Female Housing，Wire-to-Wire | https://www.molex.com/en-us/products/part-detail/988171040#documents-and-resources |
| 988171041 | 010201321 | 4 | Black | 3.33mm | NSCC Single Part，Unsealed，1.50mm，Female Housing，Wire-to-Wire | https://www.molex.com/en-us/products/part-detail/988171041#documents-and-resources |
| 988171045 | 010205325 | 4 | Green | 3.33mm | NSCC Single Part，Unsealed，1.50mm，Female Housing，Wire-to-Wire | https://www.molex.com/en-us/products/part-detail/988171045#documents-and-resources |
| 988171048 | 010208328 | 4 | Gray | 3.33mm | NSCC Single Part，Unsealed，1.50mm，Female Housing，Wire-to-Wire | https://www.molex.com/en-us/products/part-detail/988171048#documents-and-resources |
| 988221040 | 07719EV4F9 | 4 | White | 3.33mm | NSCC, Male Pin Connector，Non-Sealed | https://www.molex.com/en-us/products/part-detail/988221040#documents-and-resources |
| 988221041 | 07711EV4F1 | 4 | Black | 3.33mm | NSCC, Male Pin Connector，Non-Sealed | https://www.molex.com/en-us/products/part-detail/988221041#documents-and-resources |
| 988221045 | 07715EV4F5 | 4 | Green | 3.33mm | NSCC, Male Pin Connector，Non-Sealed | https://www.molex.com/en-us/products/part-detail/988221045#documents-and-resources |
| 988211060 | 010409329 | 6 | White | NSCC，Receptacle Connector Hybrid，Single Part，Unsealed | https://www.molex.com/en-us/products/part-detail/988211060#documents-and-resources | |
| 988211061 | 010401321 | 6 | Black | NSCC，Receptacle Connector Hybrid，Single Part，Unsealed | https://www.molex.com/en-us/products/part-detail/988211061#documents-and-resources | |
| 988211065 | 010405325 | 6 | Green | NSCC，Receptacle Connector Hybrid，Single Part，Unsealed | https://www.molex.com/en-us/products/part-detail/988211065#documents-and-resources | |
| 988211068 | 010408328 | 6 | Gray | NSCC，Receptacle Connector Hybrid，Unsealed，Single Part | https://www.molex.com/en-us/products/part-detail/988211068#documents-and-resources | |
| 988251060 | 08319EV6F9 | 6 | White | NSCC，Pin Connector Hybrid，Unsealed | https://www.molex.com/en-us/products/part-detail/988251060#documents-and-resources | |
| 988251061 | 08311EV6F1 | 6 | Black | NSCC，Pin Connector Hybrid，Unsealed | https://www.molex.com/en-us/products/part-detail/988251061#documents-and-resources | |
| 988251065 | 08315EV6F5 | 6 | Green | NSCC，Pin Connector Hybrid，Unsealed | https://www.molex.com/en-us/products/part-detail/988251065#documents-and-resources | |
| 988251068 | 08318EV6F8 | 6 | Gray | NSCC，Pin Connector Hybrid，Unsealed | https://www.molex.com/en-us/products/part-detail/988251068#documents-and-resources | |
| 987881201 | 19201EV10M1 | 10 | Gray | 1.50mm | NSCC，Wire-to-Wire，Receptacle Housing | https://www.molex.com/en-us/products/part-detail/987881201#documents-and-resources |
| 987881208 | 19208EV10M8 | 10 | White | 1.50mm | NSCC，Sealed Female Housing | https://www.molex.com/en-us/products/part-detail/987881208#documents-and-resources |
| 987891201 | 09211EV10F1 | 10 | Black | Unsealed，1.50mm，Male Housing, Dual Row | https://www.molex.com/en-us/products/part-detail/987891201#documents-and-resources | |
| 982731001 | 98273-1001 | 16 | Black | 3.33mm / 6.00mm | Hybrid Inline Female Housing，Right Slide Orientation, Dual Row | https://www.molex.com/en-us/products/part-detail/982731001#documents-and-resources |
| 982731002 | 98273-1002 | 16 | Green | 3.33mm / 6.00mm | Hybrid Inline Female Housing，Right Slide Orientation, Dual Row | https://www.molex.com/en-us/products/part-detail/982731002#documents-and-resources |
| 982731003 | 98273-1003 | 16 | Blue | 3.33mm / 6.00mm | Hybrid Inline Female Housing，Right Slide Orientation, Dual Row | https://www.molex.com/en-us/products/part-detail/982731003#documents-and-resources |
| 982731004 | 98273-1004 | 16 | White | 3.33mm / 6.00mm | Hybrid Inline Female Housing，Right Slide Orientation, Dual Row | https://www.molex.com/en-us/products/part-detail/982731004#documents-and-resources |
| 982731005 | 98273-1005 | 16 | Brown | 3.33mm / 6.00mm | Hybrid Inline Female Housing，Right Slide Orientation, Dual Row | https://www.molex.com/en-us/products/part-detail/982731005#documents-and-resources |
| 982731006 | 98273-1006 | 16 | Gray | 3.33mm / 6.00mm | Hybrid Inline Female Housing，Right Slide Orientation, Dual Row | https://www.molex.com/en-us/products/part-detail/982731006#documents-and-resources |
| 982761001 | 98276-1001 | 16 | Black | 3.33mm / 6.00mm | Hybrid Male Inline Housing, Dual Row | https://www.molex.com/en-us/products/part-detail/982761001#documents-and-resources |
| 982761002 | 98276-1002 | 16 | Green | 3.33mm / 6.00mm | Hybrid Male Inline Housing, Dual Row | https://www.molex.com/en-us/products/part-detail/982761002#documents-and-resources |
| 982761003 | 98276-1003 | 16 | Blue | 3.33mm / 6.00mm | Hybrid Male Inline Housing, Dual Row | https://www.molex.com/en-us/products/part-detail/982761003#documents-and-resources |
| 982761004 | 98276-1004 | 16 | White | 3.33mm / 6.00mm | Hybrid Male Inline Housing, Dual Row | https://www.molex.com/en-us/products/part-detail/982761004#documents-and-resources |
| 982761005 | 98276-1005 | 16 | Brown | 3.33mm / 6.00mm | Hybrid Male Inline Housing, Dual Row | https://www.molex.com/en-us/products/part-detail/982761005#documents-and-resources |
| 982761006 | 98276-1006 | 16 | Gray | 3.33mm / 6.00mm | Hybrid Male Inline Housing, Dual Row | https://www.molex.com/en-us/products/part-detail/982761006#documents-and-resources |
| 981221001 | 98122-1001 | 30 | Black | 3.33mm / 4.20mm | Hybrid Female Housing，Sealed，Right Slide Orientation | https://www.molex.com/en-us/products/part-detail/981221001#documents-and-resources |
| 981221005 | 98122-1005 | 30 | Black | 3.33mm / 4.20mm | Hybrid Female Housing，Sealed，Left Slide Orientation | https://www.molex.com/en-us/products/part-detail/981221005#documents-and-resources |
| 981221006 | 98122-1006 | 30 | Brown | 3.33mm / 4.20mm | Hybrid Female Housing，Sealed，Left Slide Orientation | https://www.molex.com/en-us/products/part-detail/981221006#documents-and-resources |
| 981221007 | 98122-1007 | 30 | Gray | 3.33mm / 4.20mm | Hybrid Female Housing，Sealed，Left Slide Orientation | https://www.molex.com/en-us/products/part-detail/981221007#documents-and-resources |
| 987611001 | 98761-1001 | 30 | Black | 3.33mm / 4.20mm | Hybrid Male Connector，Sealed | https://www.molex.com/en-us/products/part-detail/987611001#documents-and-resources |
NSCC connector Applications
- Air Bag Sensors: Ensures secure and stable connections for critical airbag deployment systems, meeting stringent safety requirements.
- Air Conditioning: Provides robust connectivity for climate control modules, enabling seamless operation and user comfort.
- Anti-Theft Systems: Supports electronic security components such as immobilizers and alarms, enhancing vehicle security.
- Engine Control Units (ECUs): Facilitates high-performance connections for ECUs, ensuring precise control and diagnostics of engine operations.
- Indicator Panels: Connects dashboard displays and indicators, delivering reliable signal transmission for essential driver information.
- Seat Interconnections: Powers and controls seat adjustment motors, heaters, and occupancy sensors for enhanced passenger comfort.
- Audio, Navigation, and Infotainment Systems: Delivers high-quality signal integrity for multimedia systems, ensuring a superior user experience.
- Steering Controls: Integrates with steering column electronics, such as multifunction switches and electronic steering locks.
- Lighting: Provides dependable connections for interior and exterior lighting, including LEDs, headlights, and taillights.
- Steering Systems: Supports advanced steering technologies like electric power steering and adaptive steering modules.
- Switches: Connects various switches within the vehicle, including toggle, rotary, and push-button controls, for diverse functionalities.
Molex NSCC Connectors are engineered for dependable performance across a wide spectrum of automotive and electronic applications. From safety-critical systems like airbags and anti-theft solutions to user-centric features such as infotainment and climate control, these connectors provide the reliability and flexibility required in demanding environments. This list, while extensive, is not exhaustive and underscores the adaptability of Molex NSCC Connectors in meeting diverse connectivity challenges.
Support Custom Wire Harness Assembly
- Connector circuits: 2 - 30Pin
- Wire Gauge: 18 - 20AWG, depends on real needs
- Wire Colors: Available in a wide range including white, black, red, yellow, blue, green, brown, orange, purple, grey, and more.
- Wire Length: Fully customizable to your specifications.
- Wiring Diagram: Tailor-made to meet your project needs.
- Custom type: Fully customizable to your specifications.
- Minimum Order: 50 pieces per order.
Customize Your Wire Harness
Send your sample or drawing/schematic for quote price→ Feedback with quotation(1~3 days) → Confirm quotation → Arrange sample you for approval→ [Make mold if needed (7 days) →Mold test] → Making samples(1~3 days)→ Samples test(Approval) → place order for Mass production(2~3 weeks)→ Quality checking→ Packing → Delivery → After Service → Repeat Order.
