Molex OneBlade Connector

The Molex OneBlade 1.00mm-pitch Wire-to-Board Connector System is a versatile, high-performance connector solution optimized for reliable and efficient assembly. Featuring a robust friction lock, OneBlade connectors ensure secure mating retention between the header and harness, adding to their durability and stability during use. The single housing design provides flexible orientation options, as it can be configured for either vertical or right-angle headers, making it ideal for a wide range of design layouts. Its unique dual-function solder tab acts both as a fitting nail and a solder tail, reducing the number of parts needed and simplifying assembly processes. This connector also incorporates a dual-point contact structure that strengthens electrical connection reliability, even in demanding environments. Designed to operate efficiently within a temperature range of -40°C to +105°C, OneBlade connectors support applications in home appliances, consumer electronics, data centers, and connected home systems, offering a dependable solution for secure and space-saving connections in modern, high-density electronic designs.

OneBlade Connector Features

• Friction lock
• Dual-point contact design
• Integrated nail and terminal in a single component
• Single connector housing used interchangeably as a vertical or right-angle header
• Dual-function solder tab
• Current up to 2.5A
• 2 to 8 positions
• -40°C to +105°C operating temperature range

OneBlade Connector Specifications Chart

OneBlade Connector Applications

Home Appliances

• Washing Machines: These connectors facilitate efficient signal and power distribution for control panels, sensors, and motors, contributing to reliable operation and extended appliance life.
• Refrigerators: Employed in refrigeration units, they connect control modules, display screens, and other critical components, ensuring stable performance and energy efficiency.
• Air Conditioners: OneBlade connectors are instrumental in linking control boards, temperature sensors, and fans, optimizing cooling performance and system responsiveness.
• Vacuum Cleaners: Used for wiring main circuits and sensor systems, these connectors help vacuum cleaners operate with consistent power and reliable functionality.

Consumer Desktop Computers

The compact design of OneBlade connectors makes them ideal for desktop computers, where they manage connections between the motherboard, power supply units, and peripheral components like hard drives and graphics cards, providing both data and power transmission within tight spaces.

Data Centers

• Servers: In server assemblies, these connectors are crucial in compact wiring configurations, enabling quick, stable connections for high-density boards, network cards, and power supplies.
• Routers: OneBlade connectors provide compact and secure connections within routers, aiding in high-speed data processing, and supporting the complex wiring needs of network operations.

Smart Speakers in a Connected Home

These connectors support the compact, efficient designs needed for smart speakers, facilitating connections between voice processing units, Wi-Fi modules, and speakers, enabling seamless interaction in smart home systems.

This list highlights common uses for the Molex OneBlade 1.00mm-Pitch Connectors, though the potential applications extend beyond these examples.

Support Custom Wire Harness Assembly

• Connector circuits: 2 - 8 Pin
• Wire Gauge: 28 - 32AWG, depending on real needs
• Wire Colors: Available in a wide range including white, black, red, yellow, blue, green, brown, orange, purple, grey, and more.
• Wire Length: Fully customizable to your specifications.
• Wiring Diagram: Tailor-made to meet your project needs.
• Custom type: Fully customizable to your specifications.
• Minimum Order: 100 pieces per order.

Customize Your Wire Harness

Send your sample or drawing/schematic for quote price→ Feedback with quotation(1~3 days) → Confirm quotation → Arrange sample you for approval→ [Make mold if needed (7 days) →Mold test] → Making samples(1~3 days)→ Samples test(Approval) → place order for Mass production(2~3 weeks)→ Quality checking→ Packing → Delivery → After Service → Repeat Order.
