Molex Pico-SPOX Connector

The Molex Pico-SPOX Wire-to-Board Connector System is designed to deliver exceptional reliability and ease of use in compact applications. This system features a dual-point contact design that enhances electrical reliability and reduces the risk of disconnection, while the anti-fish hooking mechanism improves handling efficiency during harness assembly. The connectors incorporate a locking tang on the contact, ensuring secure housing retention and a friction lock that firmly holds the receptacle housing and headers in place upon mounting. The 1.50mm (0.059") pitch Pico-SPOX™ connectors further simplify usage with a lead-in chamber on the receptacle, facilitating seamless mating. Fully shrouded headers protect the pins from damage, while polarized mating geometry prevents mismating between the header and receptacle. Additionally, these connectors are finished with lead-free plating, offering a sustainable solution without compromising performance. Compact and reliable, the Pico-SPOX series is ideal for applications requiring dependable and space-efficient wire-to-board connections.

Pico-SPOX Connector Features

• Reliable two points of contact (high current capable)
• Friction lock provides good mating retention
• Polarizing features to ensure proper mating
• Box-style contact to protect the contact area
• Offered in both straight and right angle headers for design flexibility

Pico-SPOX Connector Specifications Chart

Sort by the number of circuits.

Pico-SPOX Connector Applications

Consumer Electronics

• Gaming Machines: Reliable connections for gaming consoles, arcade systems, and slot machines, ensuring signal integrity in demanding environments.
• Monitors: Compact wire-to-board solutions for space-constrained LCD and OLED displays.
• Printers: Integration into inkjet, laser, and 3D printers to ensure seamless data and power transfer.
• Set-Top Boxes: Durable connections for cable, satellite, and streaming devices, supporting stable multimedia delivery.

Data/Communications

• LCD Monitors: Efficient connections for high-resolution display interfaces, catering to desktop and portable monitor designs.
• Office Equipment: Applications include copiers, scanners, and fax machines, providing secure, space-saving wiring solutions.

Medical

• Medical Devices: Adaptable for diagnostic equipment, infusion pumps, and other compact medical devices requiring robust, high-performance wiring.
• Patient Monitors: Ensures dependable connections in devices that monitor vital signs, promoting accurate and consistent data collection.

This is not a definitive list of applications for Molex Pico-SPOX connectors. It highlights common uses but does not exclude other possibilities, making these connectors versatile for a wide range of industries.

Support Custom Wire Harness Assembly

• Connector circuits: 2 - 15 Pin
• Wire Gauge: 24 - 30AWG, depends on real needs
• Wire Colors: Available in a wide range including white, black, red, yellow, blue, green, brown, orange, purple, grey, and more.
• Wire Length: Fully customizable to your specifications.
• Wiring Diagram: Tailor-made to meet your project needs.
• Custom type: Fully customizable to your specifications.
• Minimum Order: 100 pieces per order.

Customize Your Wire Harness

Send your sample or drawing/schematic for quote price→ Feedback with quotation(1~3 days) → Confirm quotation → Arrange sample you for approval→ [Make mold if needed (7 days) →Mold test] → Making samples(1~3 days)→ Samples test(Approval) → place order for Mass production(2~3 weeks)→ Quality checking→ Packing → Delivery → After Service → Repeat Order.
