Molex Standard .062+ Connector

The Molex Standard .062"+ Pin and Socket Connectors are engineered to deliver robust performance, supporting up to 11.5A of current per circuit. These connectors are ideal for a wide range of applications, including consumer electronics, automotive, and industrial systems, where reliability and ease of maintenance are paramount. The friction-lock mechanism ensures secure mated housings, while the panel-mount locking latch enhances the stability of panel-mount applications. Features like polarization and circuit identifiers on both receptacles and plugs help prevent incorrect mating, ensuring a smooth and efficient assembly process. The connectors also incorporate dual terminal locking lances, which provide superior contact stability upon insertion, and terminal dimples that improve electrical performance and contact reliability. A circular crimp terminal design offers flexibility, allowing orientation in any direction for quick insertion and seamless wire-to-wire assembly. Additionally, the split-beam terminal design with four points of contact provides redundant, secondary current paths, further enhancing long-term reliability and overall performance. These combined features make the Molex Standard .062"+ Connectors an excellent choice for demanding applications requiring secure, high-performance connections.

Standard .062+ Connector Features

• Friction lock, Secures mated housings
• Panel-mount locking latch, Secures panel-mount style applications
• Polarization features and circuit identifiers on receptacles and plugs, Help ensure correct mating and assembly
• Dual terminal locking lances, Provide optimum contact stability when inserted into the connector housing; dimples within the terminals enhance contact reliability and electrical performance when mated.
• Circular Crimp Terminal Design, Allows orientation in any direction for quick insertion and wire-to-wire assembly
• Split-beam terminal design with 4 points of contact, Offers redundant, secondary current paths for long-term performance and reliability
• Mates With:150176/150177 and 150178/150179
• Use With: UL 1061 / UL 1007 wires
• Terminal Used: 150180/150181
• Voltage (max.): 250V
• Current (max.): 11.5A
• Operating Temperature: -40 to +105°C

Standard .062+ Connector Specifications Chart

Standard .062+ Connector Applications

Consumer / Home Appliance

• Refrigerators: Used for internal wiring that connects the power supply to components such as compressors, fans, and lighting.
• Washers & Dryers: These connectors are employed in the internal wiring for motors, control boards, and heating elements. These connectors are chosen for their durability and ease of integration into high-volume manufacturing environments where reliability and long-term performance are essential.

Lighting

• Interior Lighting: Used in automotive, residential, and commercial interior lighting for connecting wiring to light fixtures, ballasts, and drivers.
• Fixtures: These connectors enable secure and quick assembly of lighting systems, ensuring reliable performance and maintenance-free operation.
• Ballasts: In fluorescent or HID lighting, connectors help power the ballast units that regulate the voltage and current.

Industrial

• Assembly Line Equipment: Used for power and data transmission in automated machinery, conveyors, and robotic systems.
• Industrial Control Systems: These connectors are critical in wiring control panels and industrial electronic equipment that must operate reliably under heavy-duty conditions.

Medical

• Healthcare IT: Ensuring reliable connectivity between servers, medical devices, and patient monitoring equipment in hospitals and clinics.
• Patient-Care Equipment: Used in devices such as infusion pumps, diagnostic machines, and imaging systems, where secure, long-lasting connections are needed to ensure patient safety and equipment reliability.

Automotive

• Interior Lighting: These connectors help power interior features such as dashboard lights, overhead lights, and ambient lighting systems in vehicles, offering durability and easy assembly.

Molex Standard .062"+ connectors are widely employed in a range of applications, from consumer electronics and home appliances to medical equipment and industrial machinery. Their versatility in handling both power and signal transmission makes them suitable for environments where high reliability, durability, and ease of assembly are essential. The applications listed above are just some of the more common uses, but these connectors are not limited to these sectors, and they can be found in a wide array of other electronic and electrical systems across various industries.

Support Custom Wire Harness Assembly

• Connector circuits: 1 - 10Pin
• Wire Gauge: 16 - 22AWG, depending on real needs
• Wire Colors: Available in a wide range including white, black, red, yellow, blue, green, brown, orange, purple, grey, and more.
• Wire Length: Fully customizable to your specifications.
• Wiring Diagram: Tailor-made to meet your project needs.
• Custom type: Fully customizable to your specifications.
• Minimum Order: 100 pieces per order.

Customize Your Wire Harness

Send your sample or drawing/schematic for quote price→ Feedback with quotation(1~3 days) → Confirm quotation → Arrange sample you for approval→ [Make mold if needed (7 days) →Mold test] → Making samples(1~3 days)→ Samples test(Approval) → place order for Mass production(2~3 weeks)→ Quality checking→ Packing → Delivery → After Service → Repeat Order.
