Molex Super Sabre Connector

The Molex Super Sabre Connector System is an advanced high-current interconnect solution engineered to meet the demands of versatile, power-intensive applications. It features a robust flat-blade terminal design with four electrical contact points, ensuring reliable conductivity and enhanced performance. Fully isolated terminals on both the mating sides provide added safety, while a positive latch mechanism and Terminal Position Assurance (TPA) features ensure secure and accurate connections. The connectors offer a silver-plated interface for superior conductivity and corrosion resistance and an optional UL1950-certified "Finger Test" blade for additional user protection. Delivering up to 34.0A per blade at 600V, the system supports a variety of configurations, including mixed power and signal options. This unique capability allows designers to consolidate high-current and low-current power (below 5.0A) into a single connector, optimizing space and reducing system costs. Ideal for industries such as networking, telecommunications, automotive, medical devices, and power supplies ranging from 100 to 600W, the Super Sabre Connector System offers unparalleled flexibility, performance, and reliability for modern electronic designs.

Super Sabre Connector Features

• Current rating 34.0A per blade and 600V
  • Provides excellent current density in a low-profile, small-pitch solution
• Hybrid power and signal mating combinations for wire-to-wire and wire-to-board applications
  • Design flexibility with significant space and cost savings
• The flat blade terminal design has four points of electrical contact
  • Provides reliable redundant electrical connections
• Fully isolated terminals on both mating sides
  • Protection against damage or shock
• Positive latch and TPA features (Terminal Position Assurance)
  • Prevents accidental disengagement with mating plug or header
• Silver-plated interface
  • Provides high-performance connections that eliminate fretting corrosion concerns
• UL1950 "Finger Test" certified blade (optional)
  • Meets "Finger Test" requirements for many consumer applications

Super Sabre Connector Specifications Chart

Sort by the number of circuits

Super Sabre Connector Applications

Networking and Telecommunications

• Switches: Ensuring uninterrupted network connectivity by handling high-current needs in compact spaces.
• Servers: Powering critical server components where thermal management and durability are essential.
• Base Stations: Providing efficient and stable connections for wireless communication infrastructure.
• Power Supplies: Supporting telecom power systems with high efficiency and low resistance for minimal power loss.
• Fan / Blower Racks: Maintaining cooling efficiency in high-power systems, critical for reliable operation in data centers.

Appliances / White Goods

• Ranges: Handling the high electrical loads associated with heating elements in cooktops and ovens.
• Refrigerators: Powering compressors and other high-demand components efficiently.
• Laundry Equipment: Supporting washing machines and dryers, which require robust and long-lasting electrical connections.
• Vacuums: Ensuring dependable connections for motors in heavy-duty and handheld vacuum cleaners.
• Air Conditioners: Powering compressors and fans requires reliability under high load and temperature variation.

Automotive

• Commercial Vehicles: Withstanding vibrations and harsh environments while delivering stable performance for high-current applications such as auxiliary power systems, electric brakes, and lighting.

Medical

• Patient Monitors: Delivering uninterrupted power and signal connectivity to life-critical monitoring systems.
• Diagnostic Imaging: Powering advanced imaging devices like MRI and CT scanners, where stable electrical performance is paramount.
• Therapeutic Devices: Providing reliable connections for equipment such as ventilators, infusion pumps, and dialysis machines.

Power Supplies

• 100 to 600W Units: Supporting industrial and consumer-grade power supplies with high-current and low-resistance connections, ensuring efficiency and performance in a variety of devices and systems.

While the above list highlights common applications for Molex Super Sabre Connectors, these connectors are not limited to these use cases. Their robust design, high current rating, and versatile configurations make them suitable for numerous other industries and systems requiring reliable high-performance connections.

Support Custom Wire Harness Assembly

• Connector circuits: 2 - 8 Pin
• Wire Gauge: 10 - 12AWG, depends on real needs
• Wire Colors: Available in a wide range including white, black, red, yellow, blue, green, brown, orange, purple, grey, and more.
• Wire Length: Fully customizable to your specifications.
• Wiring Diagram: Tailor-made to meet your project needs.
• Custom type: Fully customizable to your specifications.
• Minimum Order: 100 pieces per order.

Customize Your Wire Harness

Send your sample or drawing/schematic for quote price→ Feedback with quotation(1~3 days) → Confirm quotation → Arrange sample you for approval→ [Make mold if needed (7 days) →Mold test] → Making samples(1~3 days)→ Samples test(Approval) → place order for Mass production(2~3 weeks)→ Quality checking→ Packing → Delivery → After Service → Repeat Order.
