Yazaki Sealed RH Connector, Custom Wire Harness

Yazaki Sealed RH Connector Introduction

This connector is designed to provide a compact and sealed solution for various applications. With its small size, it offers convenience in installation and usage. The male terminal has a tab width of 0.64mm (.025 inches), allowing for easy connection with other devices or wires.

One notable feature of this connector is its waterproof design, ensuring reliable performance even in wet environments. It can effectively protect the internal components from moisture damage, making it suitable for outdoor or harsh conditions.

The housing of this connector incorporates internal lances and front holders, which play an important role in securing the position of the terminals. This ensures that the connections remain stable and prevents any accidental disconnections.

Moreover, the terminal itself adopts a tangle-less concept with a clean body design. This not only enhances its aesthetic appeal but also makes it easier to handle during installation or maintenance procedures.

Additionally, this connector is compatible with HS connectors, providing flexibility in various wiring configurations. It supports both "wire-to-wire" and "wire-to-devices" connections, offering versatility for different application requirements.

Overall, this connector combines compactness, reliability, and ease of use into one package. Its waterproof properties make it suitable for diverse environments while its secure terminal positioning guarantees stable connections. Whether used in industrial settings or consumer electronics products, this connector proves to be a practical choice for efficient electrical connectivity solutions.

Connector Specifications Chart

Support Custom Wire Harness Assembly

• Connectors: 2P to 12P.
• Wire Gauge:
  • depends on your needs
  • recommend by us
• Wire Colors: Available in a wide range including white, black, red, yellow, blue, green, brown, orange, purple, grey, and more.
• Wire Length: Fully customizable to your specifications.
• Wiring Diagram: Tailor-made to meet your project needs.
• Custom type:
  • Send drawing to customize.
  • Send a sample to customize.
  • Tell us as many details as possible to customize.
• Minimum Order: 50 pieces per order.

Customize Your Wire Harness

Send your sample or drawing/schematic for quote price→ Feedback with quotation(1~3 days) → Confirm quotation → Arrange sample you for approval→ [Make mold if needed (7 days) →Mold test] → Making samples(1~3 days)→ Samples test(Approval) → place order for Mass production(2~3 weeks)→ Quality checking→ Packing → Delivery → After Service → Repeat Order.
