1-1703494-1 TE AMP original brand housing plastic automotive connector

Configuration Features

• Number of Positions : 3

• Number of Rows: 1

Electrical Characteristics

• Operating Voltage (VDC): 14

• Nominal Voltage Architecture (V): 12

Body Features

• Cable Exit Angle: 180°

• Primary Product Color: Black

• Connector & Keying Code: A

Contact Features

• Contact Type: Tab

• Contact Size: 1.2mm

• Contact Current Rating (Max) (A): 25

Mechanical Attachment

• Mating Alignment: With

• Mating Alignment Type: Keyed

• Strain Relief: Without

• Connector Mounting Type: Cable Mount (Free-Hanging)

• Terminal Position Assurance: Yes

Housing Features

• Housing Material: PBT GF

• Centerline (Pitch): 4 mm [ .157 in ]

Dimensions

• Product Length: 18.8 mm [ .74 in ]

• Product Width: 44 mm [ 1.732 in ]

• Connector Height: 14.95 mm [ .589 in ]

Usage Conditions

• Operating Temperature (Max): 130 °C [ 266 °F ]

• Operating Temperature Range: -40 – 130 °C [ -40 – 266 °F ]

Operation/Application

• Circuit Application: Power

Packaging Features

• Packaging Method: Box

• Packaging Quantity: 1400

Other

• Connector Position Assurance Capable: No

• Serviceable: Yes
