PRODUCT
JST SM2.5 2pin housing UL2468 style wire assembly
red and black 22AWG doubling wire
JST SM series 2.5mm pitch 2pin equivalent parts
3mm twist and tinned conductors
JST 2pin housing UL2468 style wire assembly
Custom wire harnesses are an essential component in many electronic devices, providing a reliable and efficient means of transmitting power and data. This particular wire harness boasts red and black 22AWG doubling wires, ensuring optimal conductivity and durability.
The JST SM series 2.5mm pitch 2pin equivalent parts used in this custom wire harness are renowned for their high-quality construction and exceptional performance. These components have been carefully selected to ensure that the wire harness operates flawlessly under even the most demanding conditions.
To easy connect any other device, like PCB, this custom wire harness features 3mm twist and tinned conductors to soldering. This design ensures that the wires remain convenient connected
Whether you're working on a complex industrial project or simply need a reliable wiring solution for your home electronics, custom wire harness at our company is sure to exceed your expectations. With its superior quality control, expert craftsmanship, and unparalleled production capabilities, it's no wonder why so many people trust hooha harness for all their wiring needs!
specifications:
| Products name: | JST SM 2.5mm series 2pin housing UL2468 style wire assembly |
| Classification: | wire to board |
| Application: | power supply |
| Wire/cable style: | UL2468 |
| Wire/cable gauge: | 22AWG |
| Wire rated voltage | 300V |
| Wire rated temperature: | 80℃ |
| Wire/cable materials: | PVC |
| Wire/cable length: | 550±10mm |
| Wire color: | red and black |
| Connector type | Molex 2pin equivalents |
| Connector materials: | PA66 |
| Warranty: | 3-Years |
| Testing way: | continuity test |
| Carton size: | 45*30*25cm |
| Packing way: | customize |
| RoHS compliant: | Yes |
| ULcertificate: | Yes |
| TS16949 certificate: | Yes |
| ISO9001 certificate: | Yes |
| Sample Fee: | free |
| Sample lead time: | within 3 days |
| Bulk lead time: | 15~25 days |
| Supply capacity: | 3000pcs per day |
| MOQ: | 500pcs |
| OEM service: | Yes |
| Trade term: | EXW, FOB Shenzhen, EXPRESS |
| Payment term: | TT(30 % deposit , 70% balance), Credit card, Escrow. |
| Shipping way: | Door to Door(UPS / DHL / FedEx / TNT / EMS), By air, By ship |
| Port: | Shenzhen, Guangzhou |
Details:
Related products:
How to custom your own wire harness?
Send your sample or drawing/schematic for quote price→ Feedback with quotation(1~3 days) → Confirm quotation → Arrange sample you for approval→ [Make mold if need(7 days) →Mold test] → Making samples(1~3 days)→Samples test(Approval) →place order for Mass production(2~3 weeks)→Quality checking→Packing →Delivery →After Service →Repeat Order.
