Molex 51004 connector custom wire harness assembly

Introduction

When it comes to wire-to-board connections in compact electronic devices, the Molex 51004 series connector stands out as a reliable and versatile solution. This article provides an overview of the Molex 51004 series connector, highlighting its key features, applications, and benefits. Whether you're an engineer looking for a compact interconnect solution or an electronics enthusiast interested in learning more about connectors, this article will shed light on the Molex 51004 series.

Key Features

The Molex 51004 series connector offers several noteworthy features that make it an attractive choice for various applications:

1. Compact Design: With a low-profile and compact footprint, the Molex 51004 connector saves valuable space in electronic devices, making it ideal for applications where size is a critical factor.

2. Secure Connection: The connector incorporates a reliable latching mechanism that ensures a secure mating connection, preventing accidental disconnections due to vibrations or movement.

3. Dual-Contact Design: The 51004 series features a dual-contact terminal design, providing redundancy and enhanced electrical reliability, even in demanding environments.

4. High Current Capacity: Despite its small size, the connector is capable of handling relatively high currents, making it suitable for power applications that require efficient power transmission.

Applications

The Molex 51004 series connector finds applications in a wide range of industries, including:

1. Consumer Electronics: From smartphones and tablets to wearables and portable devices, the compact form factor of the 51004 series makes it an excellent choice for space-constrained consumer electronic devices.

2. Industrial Automation: In industrial settings, where reliability and space optimization are critical, the Molex 51004 connector is well-suited for connecting sensors, actuators, and control modules.

3. Automotive Electronics: With its robust design and ability to handle high currents, the 51004 series is suitable for automotive applications such as infotainment systems, lighting modules, and interior electronics.

4. Medical Devices: Medical equipment often requires compact and reliable connectors and the Molex 51004 series meets these requirements, making it suitable for various medical devices and diagnostic equipment.

Benefits

Here are some key benefits of using the Molex 51004 series connector:

1. Space Savings: The compact size of the connector allows for efficient use of limited space, enabling designers to create smaller and more compact electronic devices.

2. Reliability: The dual-contact design and secure latching mechanism ensure a reliable and robust connection, minimizing the risk of signal loss or intermittent connections.

3. Ease of Assembly: The connector's user-friendly design simplifies the assembly process, saving time and effort during production.

4. Versatility: The 51004 series connector is available in various configurations, including different pin counts and options for vertical or right-angle orientations, providing flexibility to meet specific application requirements.

Conclusion

The Molex 51004 series connector offers a compact, reliable, and versatile solution for wire-to-board connections in a wide range of industries. Its space-saving design, secure connection, and high current capacity make it a preferred choice for many electronic applications. Whether in consumer electronics, industrial automation, automotive, or medical devices, the Molex 51004 series connector delivers the performance and reliability needed for successful interconnect solutions.
