BNC connector to RJ45 video ethernet media converter cctv cable adapter

BNC connector to RJ45 video ethernet media converter CCTV cable adapter

The BNC connector to RJ45 video ethernet media converter CCTV cable is an custom cable tool for the one looking to connect their CCTV cameras to a network devices. This cable allows you to convert the analog signal from camera into a digital signal that can be transmitted over an Ethernet network.

With this custom cable, it'll be able to easily connect CCTV cameras to the existing network infrastructure, allowing you to monitor and manage your surveillance footage from anywhere in the world.

Send us your custom data cable drawing or diagram if you are also looking for a custom data cable assembly service, we are a professinal custom data cable and wire harness manufacturer since 2001, have rich experience to custom any type of cable, all cable products produce carry out IPC/WHMA-A-620 standard.

RJ45 to BNC wiring diagram

RJ45 Pin-7 to BNC center pin

RJ45 Pin-8 to BNC metal shell

Of course, this is a customized wiring diagram, you can request RJ45 any pins to connect BNC connectors, like:

Details

RJ45 to BNC cable Applications

1. Network Surveillance Systems

Many older CCTV systems use BNC connectors for analog video signals. An RJ45 to BNC cable can be used in systems that need to integrate newer IP cameras (which use Ethernet cables) with older analog infrastructure.

2. Networking Equipment

In some cases, legacy networking equipment that uses BNC connectors for coaxial cable connections (such as older modems, routers, or network analyzers) might need to connect to modern networking devices that use RJ45 Ethernet connectors. The cable can serve as a bridge between the two technologies.

3. Broadband over Coax

Some networking setups use broadband over coax (such as MoCA and Multimedia over Coax Alliance) to extend Ethernet networks over existing coaxial cable installations. An RJ45 to BNC converter might be part of such a setup, especially in hybrid environments.

4. Amateur Radio and Broadcasting

In certain radio and broadcasting setups, there might be a need to interface modern digital equipment with older analog systems. An RJ45 to BNC cable can help in creating this interface, especially in data transfer scenarios.

Related Network Cable Cases

Customized Your Cable Adapter Processing Flow:

Send your sample or drawing request → Feedback with quotation(1~3 days) → Confirm quotation and make payment → Make mold if needed (7 days) →Mold test → Making samples(1~3 days)→Samples test(Approval) →place order for Mass production(2~3 weeks)→Quality checking→Packing →Delivery →After Service →Repeat Order.
